ViandPro – Aria Flush Fit Ceiling Hood 90×30 Black- Fits Between Joists – Ducted Or Recirculated – VP-CH93BLK

Product code: VP-CH93BLK

(8 customer reviews)

90cm x 30cm ceiling extractor , all black, 2 LED colour change lights, ducted or recirculation installation, remote control.

  • Black Glass Panel & Black Outer Frame
  • Filters available for recirculation
  • 3 Speeds
  • 2 x LED Colour Change Lights
  • Remote Control
  • Fits Between Joists
  • Ducted or Recirculation Installation

Save £50 with code ARIASAVE50

Low Stock
Clear

Got a question? Call 01274 541236 or click here to get in touch.







  • Product Description

    Slimline Ceiling Ducted or Recirculated Hood for Flush Fit between Joists.

    Stunning new remote control ceiling extractor with unique slimline profile. Designed to fit between standard joists (running same direction as the hob) to give a beautiful flush fit finish. (If your joists run the other way, this won’t be able to sit flush in the ceiling.)

    Featuring a central black glass hinged panel (the stainless steel washable grease filters are housed behind it) with changeable colour mood LED lighting and a black outer frame. Attractive Stainless Steel Bluetooth remote control means it’s simple to operate without reaching up, but the hood also comes with easy touch controls for manual operation. With a powerful (and quiet) 600m3/hr motor, this will efficiently and effectively clear your kitchen of cooking smells, grease and odours. Now with a recirculation option, you don’t need to duct to an outside wall. Using a charcoal filter and a short ducting kit to vent back into the kitchen, this offers a unrivalled solution for a ceiling hood that installs in the existing ceiling line.

    The small size of the hood means it is also suitable for some undercabinet installations and chimney breast installations where range cookers are installed in the old chimney alcove. Minimum height for installation is 75/65cm gas/electric.

    Using 220 x 90cm rectangular (equivalent to 6″) ducting to maintain ease of fitting in the ceiling void (the 90mm height fits easily), you can simply duct straight to the wall and use a rectangular outlet, or convert to 150mm round for sourcing draughtproof or insulated ducting systems. The recirculation version comes with a ducting kit and everything you need to get started.


    Flush Fit Recirculation Ceiling Hood

    This is the only slimline recirculation small ceiling hood we know of that can be installed between joists in the existing ceiling line without the need to duct outside. Most recirculating hoods install below the ceiling line as they blow the cleaned air back into the kitchen from vents on the top of the hood. However, the Aria offers the ability to install flush to the ceiling line and duct back into the kitchen from a discrete ceiling vent.

    During installation, you use the flexible 220 x 90 ducting tube and round adaptor to connect the exhaust of the hood to the discrete white ceiling vent. The easy-to-replace charcoal filters are installed behind the grease filters on the hood.

    *The support beams on the diagram are a suggested installation method. You can use the clips to hang the hood on a baton across the joists.

    The diagram shows this configuration only works if the joists are running the same way as the hob. If you are installing across the joists, then no ceiling hood will fit flush to your ceiling. Please contact us if you are unsure if our non-ducted ceiling hood is suitable for your hob.


    Please refer to a tradesperson to double-check suitability for your installation.
    The product will fit between 8″ (203m) and higher joists plus 1 sheet of 12.5mm plasterboard
    203mm +12.5mm = 215.5 mm > height of product 207mm. In case of tight installations, a further board or ply can be added to the ceiling ( imagine like a picture frame around the hood) and finished to match the ceiling giving you the room needed in the void between joists.

    Minimum Niche Dimensions for installation L 860mm W 280mm H 207mm

    • Overall Size L 900 x D 320mm x H 207mm
    • Motor rating 600m3/hr
    • Hood Extraction Rate 411.1m3/hr (EN 61591)
    • Maximum height above hob 1.6m
    • Noise 54 – 59dB
    • Ducted or recirculation
    • Weight 15.3kg

    Manufacturers Website

  • Product Specifications
    Manufacturer Name

    ViandPro

    Division Name

    Cooking

    Major Department Name

    Hoods

    Department Name

    Ceiling Hoods

    Colour

    Black

    Features | Benefits

    900 x 300 ceiling extractor, 2 colour change LED lights, ducted out installation, remote control.

    Brand Name

    ViandPro

    Width

    900

    Height

    207

    Depth

    320

    Extraction Rate

    411

    Energy Efficiency Class

    D

    Noise Level

    59

    Typology

    Island/Ceilling

    Type of Light

    LED

    Grease Filter Type

    aluminium

    Number of Hood Speeds

    3

    Diameter of Air Outlet

    220 x 90

    lbmx-document-name-3

    Ducting Information

    lbmx-document-url-3

    https://www.modernlivingdirect.co.uk/wp-content/uploads/2022/07/Aria-Ducting-Notes.pdf

    Variation Details

    Ducted Version, Recirculation Version

    Venting Types

    Ducted/Recirculating

  • Delivery Information

    This item is in stock in our warehouse and available for immediate dispatch.

    Standard delivery will be by courier and with you in 2 – 3 working days.  You will receive tracking updates and a 2 hour delivery window on the day of delivery.

    You have the option of selecting Next Working Day delivery in the checkout process.  The cut off for same day dispatch is 1pm.

  • Product Reviews

    8 reviews for ViandPro – Aria Flush Fit Ceiling Hood 90×30 Black- Fits Between Joists – Ducted Or Recirculated – VP-CH93BLK

    1. Simon W (verified owner)

      Works well and looks good. Bit tricky to install.

    2. D Eddleston (verified owner)

      This unit has a very good price for what it includes.

    3. G Tipper (verified owner)

      Had some difficulty with the installation as it was a tight fit, but once in looks good and fuctions fine.

    4. L Buttner (verified owner)

      I was a bit unsure with the ducting options and ended up with a couple of extra bits I didn’t need, so be careful with that – but the hood itself works well and we are happy overall.

    5. A Jeffries (verified owner)

      I am delighted with the ceiling hood and the service I received.

    6. V Bayford (verified owner)

      All good.

    7. T Bowe (verified owner)

      Fast delivery. As described

    8. J Brixey (verified owner)

      It’s really efficient and quiet, I highly recommend it.
